Safety Precautions

For the individual precautions for each Switch, refer to the Precautions section of each Switch.

If the Limit Switch incorporates a ground terminal, be sure to ground it through an appropriate wire, otherwise an electric shock may be received.

Be sure to connect a fuse with a breaking current 1.5 to 2 times the rated current to the Limit Switch in parallel in order to protect the Limit Switch from damage due to short-circuiting.

Maintain an appropriate insulation distance between wires connected to the Limit Switch.

If the Limit Switch has no ground terminal, ground the mounting panel to which the Limit Switch is mounted unless the Limit Switch is of double insulation construction falling under class II. Such models (e.g., the D4D-N, D4D-R, D4DS, SHL, D4E-N, ZC, or D4MC) ensure good insulation characteristics. Therefore, no ground terminals are incorporated.

Do not use the Limit Switch in places with flammable or explosive gas without taking any countermeasures against explosion or fires. Otherwise switching arcs or heat radiation may cause a fire or explosion.
Be sure to protect the Limit Switch with appropriate explosion-proof barriers or use a Limit Switch of explosion-proof construction. The Explosion-proof Limit Switch is not available for use in all types of gas or locations. Refer to the Explosion-proof Device General Catalog for details.

The life of the Limit Switch greatly varies with switching conditions. Before using the Limit Switch, be sure to test the Limit Switch under actual conditions. Make sure that the number of switching operations is within the permissible range.
If a deteriorated Switch is used continuously, insulation failures, contact weld, contact failures, switch damage, or switch burnout may result.

Some types of load have a great difference between normal current and inrush current. Make sure that the inrush current is within the permissible value. The greater the inrush current in the closed circuit is, the greater the contact abrasion or shift will be. Consequently, contact weld, contact separation failures, or insulation failures may result. Furthermore, the Limit Switch may become broken or damaged.

Wiring

If the wiring method is incorrect, the wires may get caught by some object or the lead wires may be pulled excessively. Make sure that the lead wires are connected without extraordinary force and that the wires are supported securely.

Pay the utmost attention so that each terminal is wired correctly. If the terminal is wired incorrectly, the Limit Switch will not function. Furthermore, not only will the Limit Switch have a bad influence on the external circuit, the Limit Switch itself may become damaged or burnt.

Mounting

Do not modify the actuator, otherwise the operating characteristics and performance of the actuator will change.

Do not enlarge the mounting holes of the Limit Switch or modify the Limit Switch, otherwise insulation failures or housing damage may result. If the Limit Switch has a force separation mechanism, a modification of the Limit Switch may cause injury.

Do not apply oil, grease, or other lubricants to the moving parts of the actuator, otherwise the actuator may not operate correctly. Furthermore, intrusion of oil, grease, or other lubricants inside the Limit Switch may cause failures in the Limit Switch.

When mounting the Limit Switch to the mounting panel, maintain a minimum insulation distance of 1 mm between the mounting panel and the Limit Switch. If the insulation distance is insufficient, add an appropriate insulation guard or separator, otherwise a fire or current leakage may occur or an electric shock may be received.

Mount the Limit Switch and secure it with the specified screws tightened to the specified torque along with flat washers and springs. The actuator of the Limit Switch mounted to a panel with excessive tightening torque may not operate correctly if the Limit Switch is a pushbutton model.

Be sure to wire the Limit Switch so that the conduit opening is free of metal powder or any other impurities.

If glue or bonding agent is applied, make sure that it does not adhere to the movable parts or intrude inside the Limit Switch, otherwise the Limit Switch may not work correctly or cause contact failure. Some types of glue or bonding agent may generate a gas that may have a bad influence on the Limit Switch. Pay the utmost attention when selecting the glue or locking agent.

Do not drop or disassemble the Limit Switch, otherwise the Limit Switch will not be capable of full performance. Furthermore, the Limit Switch may become broken or burnt.

If the contacts are not turned ON or OFF over a long time, the contacts may become oxidized. Consequently, the reliability of the contacts may decrease, which may result in accidents.

Actuation of the Limit Switch over a long time may deteriorate parts of the Limit Switch and a releasing failure may result. Be sure to check the condition of the Limit Switch regularly.

Some models allow changes in head directions. When changing the head of such a model, make sure that the head is free of any foreign substance. Tighten each screw of the head to the rated torque.

Be sure to take measures so that no foreign material, oil, or water will penetrate into the Limit Switch through the conduit opening. Be sure to attach a connector suited to the cable thickness and tighten the connector securely to the rated torque.

Apply Limit Switch models incorporating a force-separation function, such as the D4BS or D4BL, for safety doors or emergency stop circuits.

Do not impose shock or vibration on the actuator while it is fully pressed. Otherwise, the actuator will partially abrade and an actuation failure may result.
