Standard Proximity Sensor

E2E

Standard Sensors for Detecting Ferrous Metals under Standard Conditions

2-Wire Models

Shielded DC 2-wire Models with No Self-diagnostic Output

E2E Lineup 2

Ap-
pear-
ance
Sensing
distance
Con-
nection
method
Cable
specifi-
cations
Po-
lar-
ity
Opera-
tion
mode
Pin
ar-
range-
ment
Appli-
cable
con-
nector
code *2
Model
M8 2 mm M12 Pre-
wired
Smartclick
Connector
Models
(0.3 m)
PUR (increased
oil-resistant)
Yes NO 1: +V,
4: 0 V
H E2E-X2D1-M1TGJ-U 0.3M
NC 1: +V,
2: 0 V
E2E-X2D2-M1TGJ-U 0.3M
PVC
(oil-resistant)
NO 1: +V,
4: 0 V
G E2E-X2D1-M1TGJ 0.3M
Pre-wired
Models
(2 m)
PUR (increased
oil-resistant)
NO --- --- E2E-X2D1-U 2M
NC E2E-X2D2-U 2M
PVC
(oil-resistant)
NO E2E-X2D1-N 2M
NC E2E-X2D2-N 2M
M12
Connector
Models
--- NO 1: +V,
4: 0 V
A E2E-X2D1-M1G
NC 1: +V,
2: 0 V
D E2E-X2D2-M1G
M8
Connector
Models
--- NO 1: +V,
4: 0 V
I E2E-X2D1-M3G
NC 1: +V,
2: 0 V
E2E-X2D2-M3G
M12 3 mm M12 Pre-
wired
Smartclick
Connector
Models
(0.3 m)
PUR (increased
oil-resistant)
Yes NO 1: +V,
4: 0 V
H E2E-X3D1-M1TGJ-U 0.3M
NC 1: +V,
2: 0 V
E2E-X3D2-M1TGJ-U 0.3M
PVC
(oil-resistant)
NO 1: +V,
4: 0 V
G E2E-X3D1-M1TGJ 0.3M
Pre-wired
Models
(2 m)
PUR (increased
oil-resistant)
NO --- --- E2E-X3D1-U 2M
NC E2E-X3D2-U 2M
PVC
(oil-resistant)
NO E2E-X3D1-N 2M *1
NC E2E-X3D2-N 2M
M12
Connector
Models
--- NO 1: +V,
4: 0 V
A E2E-X3D1-M1G *1
NC 1: +V,
2: 0 V
D E2E-X3D2-M1G
M12
Standard
Pre-wired
Connector
Models
(0.3 m)
PVC
(oil-resistant)
Yes NO 1: +V,
4: 0 V
A E2E-X3D1-M1GJ 0.3M
NC 1: +V,
2: 0 V
D E2E-X3D2-M1GJ 0.3M
No *3 NO (3, 4):
(+V, 0 V)
C E2E-X3D1-M1J-T 0.3M
NC (1, 2):
(+V, 0 V)
D ---
M18 7 mm M12 Pre-
wired
Smartclick
Connector
Models
(0.3 m)
PUR (increased
oil-resistant)
Yes NO 1: +V,
4: 0 V
H E2E-X7D1-M1TGJ-U 0.3M
NC 1: +V,
2: 0 V
E2E-X7D2-M1TGJ-U 0.3M
PVC
(oil-resistant)
NO 1: +V,
4: 0 V
G E2E-X7D1-M1TGJ 0.3M
Pre-wired
Models
(2 m)
PUR (increased
oil-resistant)
NO --- --- E2E-X7D1-U 2M
NC E2E-X7D2-U 2M
PVC
(oil-resistant)
NO E2E-X7D1-N 2M *1
NC E2E-X7D2-N 2M
M12
Connector
Models
--- NO 1: +V,
4: 0 V
A E2E-X7D1-M1G *1
NC 1: +V,
2: 0 V
D E2E-X7D2-M1G
M12
Standard
Pre-wired
Connector
Models
(0.3 m)
PVC
(oil-resistant)
Yes NO 1: +V,
4: 0 V
A E2E-X7D1-M1GJ 0.3M
NC 1: +V,
2: 0 V
D E2E-X7D2-M1GJ 0.3M
No *3 NO (3, 4):
(+V, 0 V)
C E2E-X7D1-M1J-T 0.3M
NC (1, 2):
(+V, 0 V)
D E2E-X7D2-M1J-T 0.3M
M30 10 mm M12 Pre-
wired
Smartclick
Connector
Models
(0.3 m)
PUR (increased
oil-resistant)
Yes NO 1: +V,
4: 0 V
H E2E-X10D1-M1TGJ-U 0.3M
NC 1: +V,
2: 0 V
E2E-X10D2-M1TGJ-U 0.3M
PVC
(oil-resistant)
NO 1: +V,
4: 0 V
G E2E-X10D1-M1TGJ 0.3M
Pre-wired
Models
(2 m)
PUR (increased
oil-resistant)
NO --- --- E2E-X10D1-U 2M
NC E2E-X10D2-U 2M
PVC
(oil-resistant)
NO E2E-X10D1-N 2M *1
NC E2E-X10D2-N 2M
M12
Connector
Models
--- NO 1: +V,
4: 0 V
A E2E-X10D1-M1G *1
NC 1: +V,
2: 0 V
D E2E-X10D2-M1G
M12
Standard
Pre-wired
Connector
Models
(0.3 m)
PVC
(oil-resistant)
Yes NO 1: +V,
4: 0 V
A E2E-X10D1-M1GJ 0.3M
PVC
(oil-resistant)
NC 1: +V,
2: 0 V
D E2E-X10D2-M1GJ 0.3M
PVC
(oil-resistant)
No *3 NO (3, 4):
(+V, 0 V)
C E2E-X10D1-M1J-T 0.3M
PVC
(oil-resistant)
NC (1, 2):
(+V, 0 V)
D E2E-X10D2-M1J-T 0.3M

*1. Models with different frequencies are also available. The model number is E2E-X[]D15 (example: E2E-X3D15-N 2M).
*2. Refer to Data Sheet for details.
*3. The residual voltage for models without polarity is 5 V, so use caution concerning the connection load interface
       conditions (e.g., PLC ON voltage).
       Refer to Data Sheet.

Shielded DC 2-Wire UL-recognized Models with No Self-diagnostic Output

E2E Lineup 4

Ap-
pear-
ance
Sensing
distance
Connection
method
Cable
specifi-
cations
Po-
lar-
ity
Opera-
tion
mode
Pin
ar-
range-
ment
Appli-
cable
con-
nector
code *
Model
M8 2 mm M12 Pre-wired
Smartclick
Connector
Models (0.3 m)
PVC
(oil-
resistant)
Yes NO 1: +V,
4: 0 V
G E2E-X2D1-M1TGJ-US 0.3M
NC 1: +V,
2: 0 V
E2E-X2D2-M1TGJ-US 0.3M
Pre-wired
Models (2 m)
NO --- --- E2E-X2D1-US 2M
NC E2E-X2D2-US 2M
M12 3 mm M12 Pre-wired
Smartclick
Connector
Models (0.3 m)
NO 1: +V,
4: 0 V
G E2E-X3D1-M1TGJ-US 0.3M
NC 1: +V,
2: 0 V
E2E-X3D2-M1TGJ-US 0.3M
Pre-wired
Models (2 m)
NO --- --- E2E-X3D1-US 2M
NC E2E-X3D2-US 2M
M18 7 mm M12 Pre-wired
Smartclick
Connector
Models (0.3 m)
NO 1: +V,
4: 0 V
G E2E-X7D1-M1TGJ-US 0.3M
NC 1: +V,
2: 0 V
E2E-X7D2-M1TGJ-US 0.3M
Pre-wired
Models (2 m)
NO --- --- E2E-X7D1-US 2M
NC E2E-X7D2-US 2M
M30 10 mm M12 Pre-wired
Smartclick
Connector
Models (0.3 m)
NO 1: +V,
4: 0 V
G E2E-X10D1-M1TGJ-US 0.3M
NC 1: +V,
2: 0 V
E2E-X10D2-M1TGJ-US 0.3M
Pre-wired
Models (2 m)
NO --- --- E2E-X10D1-US 2M
NC E2E-X10D2-US 2M

* Refer to Data Sheet for details.

Unshielded DC 2-Wire Models with No Self-diagnosis Output

E2E Lineup 6

Ap-
pear-
ance
Sensing
distance
Con-
nection
method
Cable
specifi-
cations
Po-
lar-
ity
Opera-
tion
mode
Pin
ar-
range-
ment
Appli-
cable
con-
nector
code *2
Model
M8 4 mm Pre-wired
Models (2 m)
PVC
(oil-resistant)
Yes NO --- --- E2E-X4MD1 2M
NC E2E-X4MD2 2M
M12
Connector
Models
--- NO 1: +V,
4: 0 V
A E2E-X4MD1-M1G
NC 1: +V,
2: 0 V
D E2E-X4MD2-M1G
M8
Connector
Models
--- NO 1: +V,
4: 0 V
I E2E-X4MD1-M3G
NC 1: +V,
2: 0 V
E2E-X4MD2-M3G
M12 8 mm M12 Pre-wired
Smartclick
Connector
Models (0.3 m)
PVC
(oil-resistant)
NO 1: +V,
4: 0 V
G E2E-X8MD1-M1TGJ 0.3M
Pre-wired
Models (2 m)
PVC
(oil-resistant)
NO --- --- E2E-X8MD1 2M *1
NC E2E-X8MD2 2M
M12
Connector
Models
--- NO 1: +V,
4: 0 V
A E2E-X8MD1-M1G *1
NC 1: +V,
2: 0 V
D E2E-X8MD2-M1G
M12 Standard
Pre-wired
Connector
Models (0.3 m)
PVC
(oil-resistant)
NO 1: +V,
4: 0 V
A E2E-X8MD1-M1GJ 0.3M
NC 1: +V,
2: 0 V
D ---
M18 14 mm M12 Pre-wired
Smartclick
Connector
Models (0.3 m)
PVC
(oil-resistant)
NO 1: +V,
4: 0 V
G E2E-X14MD1-M1TGJ 0.3M
Pre-wired
Models (2 m)
PVC
(oil-resistant)
NO --- --- E2E-X14MD1 2M *1
NC E2E-X14MD2 2M
M12
Connector
Models
--- NO 1: +V,
4: 0 V
A E2E-X14MD1-M1G *1
NC 1: +V,
2: 0 V
D E2E-X14MD2-M1G
M12 Standard
Pre-wired
Connector
Models (0.3 m)
PVC
(oil-resistant)
NO 1: +V,
4: 0 V
A E2E-X14MD1-M1GJ 0.3M
NC 1: +V,
2: 0 V
D E2E-X14MD2-M1GJ 0.3M
M30 20 mm M12 Pre-wired
Smartclick
Connector
Models (0.3 m)
PVC
(oil-resistant)
NO 1: +V,
4: 0 V
G E2E-X20MD1-M1TGJ 0.3M
Pre-wired
Models (2 m)
PVC
(oil-resistant)
NO --- --- E2E-X20MD1 2M *1
NC E2E-X20MD2 2M
M12
Connector
Models
--- NO 1: +V,
4: 0 V
A E2E-X20MD1-M1G *1
NC 1: +V,
2: 0 V
D E2E-X20MD2-M1G
M12 Standard
Pre-wired
Connector
Models (0.3 m)
PVC
(oil-resistant)
NO 1: +V,
4: 0 V
A E2E-X20MD1-M1GJ 0.3M
NC 1: +V,
2: 0 V
D ---

*1. Models with different frequencies are also available. The model number is E2E-X[]D15 (example: E2E-X8MD15 2M).
*2. Refer to Data Sheet for details.

Unshielded DC 2-Wire UL-recognized Models with No Self-diagnostic Output

E2E Lineup 8

Ap-
pear-
ance
Sensing
distance
Con-
nection
method
Cable
specifi-
cations
Po-
lar-
ity
Opera-
tion
mode
Pin
ar-
range-
ment
Appli-
cable
con-
nector
code *
Model
M8 4 mm M12 Pre-wired
Smartclick
Connector
Models (0.3 m)
PVC
(oil-
resistant)
Yes NO 1: +V,
4: 0 V
G E2E-X4MD1-M1TGJ-US 0.3M
NC 1: +V,
2: 0 V
E2E-X4MD2-M1TGJ-US 0.3M
Pre-wired
Models (2 m)
NO --- --- E2E-X4MD1-US 2M
NC E2E-X4MD2-US 2M
M12 8 mm M12 Pre-wired
Smartclick
Connector
Models (0.3 m)
NO 1: +V,
4: 0 V
G E2E-X8MD1-M1TGJ-US 0.3M
NC 1: +V,
2: 0 V
E2E-X8MD2-M1TGJ-US 0.3M
Pre-wired
Models (2 m)
NO --- --- E2E-X8MD1-US 2M
NC E2E-X8MD2-US 2M
M18 14 mm M12 Pre-wired
Smartclick
Connector
Models (0.3 m)
NO 1: +V,
4: 0 V
G E2E-X14MD1-M1TGJ-US 0.3M
NC 1: +V,
2: 0 V
E2E-X14MD2-M1TGJ-US 0.3M
Pre-wired
Models (2 m)
NO --- --- E2E-X14MD1-US 2M
NC E2E-X14MD2-US 2M
M30 20 mm M12 Pre-wired
Smartclick
Connector
Models (0.3 m)
NO 1: +V,
4: 0 V
G E2E-X20MD1-M1TGJ-US 0.3M
NC 1: +V,
2: 0 V
E2E-X20MD2-M1TGJ-US 0.3M
Pre-wired
Models (2 m)
NO --- --- E2E-X20MD1-US 2M
NC E2E-X20MD2-US 2M

* Refer to Data Sheet for details.

Shielded DC 2-Wire Models with Self-diagnosis Output

E2E Lineup 10

Ap-
pear-
ance
Sensing
distance
Con-
nection
method
Cable
specifi-
cations
Po-
lar-
ity
Opera-
tion
mode
Pin
arrangement
Appli-
cable
con-
nector
code *2
Model
M12 3 mm Pre-wired
Models
(2 m)
PVC
(oil-
resistant)
Yes NO --- --- E2E-X3D1S 2M *1
M12
Connector
Models
--- 2: +V and diagnostic output
3: 0 V
4: +V and control output
D E2E-X3D1S-M1
M18 7 mm Pre-wired
Models
(2 m)
PVC
(oil-
resistant)
--- --- E2E-X7D1S 2M *1
M12
Connector
Models
--- 2: +V and diagnostic output
3: 0 V
4: +V and control output
D E2E-X7D1S-M1
M30 10 mm Pre-wired
Models
(2 m)
PVC
(oil-
resistant)
--- --- E2E-X10D1S 2M *1
M12
Connector
Models
--- 2: +V and diagnostic output
3: 0 V
4: +V and control output
D E2E-X10D1S-M1

*1. Models with different frequencies are also available. The model number is E2E-X[]D15S (example: E2E-X3D15S 2M).
*2. Refer to Data Sheet for details.

Unshielded DC 2-Wire Models with Self-diagnosis Output

E2E Lineup 12

Ap-
pear-
ance
Sensing
distance
Con-
nection
method
Cable
specifi-
cations
Po-
lar-
ity
Opera-
tion
mode
Pin
arrangement
Appli-
cable
con-
nector
code *2
Model
M12 8 mm Pre-wired
Models
(2 m)
PVC
(oil-
resistant)
Yes NO --- --- E2E-X8MD1S 2M *1
M12
Connector
Models
--- 2: +V and diagnostic output
3: 0 V
4: +V and control output
D E2E-X8MD1S-M1
M18 14 mm Pre-wired
Models
(2 m)
PVC
(oil-
resistant)
--- --- E2E-X14MD1S 2M *1
M12
Connector
Models
--- 2: +V and diagnostic output
3: 0 V
4: +V and control output
D E2E-X14MD1S-M1
M30 20 mm Pre-wired
Models
(2 m)
PVC
(oil-
resistant)
--- --- E2E-X20MD1S 2M *1
M12
Connector
Models
--- 2: +V and diagnostic output
3: 0 V
4: +V and control output
D E2E-X20MD1S-M1

*1. Models with different frequencies are also available. The model number is E2E-X[]MD15S (example: E2E-X8MD15S 2M).
*2. Refer to Data Sheet for details.

Connector Pin Assignments of DC 2-Wire Models

The connector pin assignments of each New E2E DC 2-Wire Model conform to IEC 947-5-2 Table III. (Only DC 2-Wire Models have been changed in comparison to the previous models.)
The following models with conventional connector pin assignments are available as well. (Only NO Models can be used.)
The cable at the below should also be used if the XW3A-P[]45-G11 Connector Junction Box is already being used.

Cable length Model
500 mm XS2W-D421-BY1

E2E Lineup 15

Models with conventional connector pin assignments are available as well.

Appearance Model
NO Applicable connector
code *
NC Applicable connector
code *
449_lu_8_1
M8 E2E-X2D1-M1 C E2E-X2D2-M1 D
M12 E2E-X3D1-M1 C E2E-X3D2-M1 D
M18 E2E-X7D1-M1 C E2E-X7D2-M1 D
M30 E2E-X10D1-M1 C E2E-X10D2-M1 D
449_lu_8_2
M8 E2E-X4MD1-M1 C E2E-X4MD2-M1 D
M12 E2E-X8MD1-M1 C E2E-X8MD2-M1 D
M18 E2E-X14MD1-M1 C E2E-X14MD2-M1 D
M30 E2E-X20MD1-M1 C E2E-X20MD2-M1 D

* Refer to Data Sheet for details.

AC 2-Wire Models Shielded Models

E2E Lineup 18

Appear-
ance
Sensing
distance
Connection
method
Cable
specifications
Opera-
tion
mode
Pin
arrangement
Applicable
connector
code *2
Model
M8 1.5 mm Pre-wired
Models (2 m)
PVC
(oil-resistant)
NO --- --- E2E-X1R5Y1 2M
NC E2E-X1R5Y2 2M
M12 2 mm Pre-wired
Models (2 m)
PVC
(oil-resistant)
NO --- --- E2E-X2Y1 2M *1
NC E2E-X2Y2 2M
M12 Connector
Models
--- NO (3, 4): (AC, AC) E E2E-X2Y1-M1
NC (1, 2): (AC, AC) F E2E-X2Y2-M1
M18 5 mm Pre-wired
Models (2 m)
PVC
(oil-resistant)
NO --- --- E2E-X5Y1 2M *1
NC E2E-X5Y2 2M
M12 Connector
Models
--- NO (3, 4): (AC, AC) E E2E-X5Y1-M1
NC (1, 2): (AC, AC) F E2E-X5Y2-M1
M30 10 mm Pre-wired
Models (2 m)
PVC
(oil-resistant)
NO --- --- E2E-X10Y1 2M *1
NC E2E-X10Y2 2M
M12 Connector
Models
--- NO (3, 4): (AC, AC) E E2E-X10Y1-M1
NC (1, 2): (AC, AC) F E2E-X10Y2-M1

*1. Models with different frequencies are also available. The model number is E2E-X[]Y[]5 (example: E2E-X5Y15 2M).
*2. Refer to Data Sheet for details.

Unshielded Models

E2E Lineup 20

Appear-
ance
Sensing
distance
Connection
method
Cable
specifications
Opera-
tion
mode
Pin
arrangement
Applicable
connector
code *2
Model
M8 2 mm Pre-wired
Models (2 m)
PVC
(oil-resistant)
NO --- --- E2E-X2MY1 2M
NC E2E-X2MY2 2M
M12 5 mm Pre-wired
Models (2 m)
PVC
(oil-resistant)
NO --- --- E2E-X5MY1 2M *1
NC E2E-X5MY2 2M
M12 Connector
Models
--- NO (3, 4): (AC, AC) E E2E-X5MY1 2M
NC (1, 2): (AC, AC) F E2E-X5MY2-M1
M18 10 mm Pre-wired
Models (2 m)
PVC
(oil-resistant)
NO --- --- E2E-X10MY1 2M *1
NC E2E-X10MY2 2M
M12 Connector
Models
--- NO (3, 4): (AC, AC) E E2E-X10MY1-M1
NC (1, 2): (AC, AC) F E2E-X10MY2-M1
M30 18 mm Pre-wired
Models (2 m)
PVC
(oil-resistant)
NO --- --- E2E-X18MY1 2M *1
NC E2E-X18MY2 2M
M12 Connector
Models
--- NO (3, 4): (AC, AC) E E2E-X18MY1-M1
NC (1, 2): (AC, AC) F E2E-X18MY2-M1

*1. Models with different frequencies are also available. The model number is E2E-X[]MY[]5 (example: E2E-X5MY15 2M).
*2. Refer to Data Sheet for details.

AC 2-Wire Models Shielded Models (There are no unshielded models.)

E2E Lineup 22

Appear-
ance
Sensing
distance
Connection
method
Cable
specifications
Operation
mode
Pin
arrange-
ment
Applicable
connector
code
Model
M12 3 mm Pre-wired Models (2 m) PVC (oil-resistant) NO --- --- E2E-X3T1 2M
M18 7 mm Pre-wired Models (2 m) PVC (oil-resistant) --- --- E2E-X7T1 2M
M30 10 mm Pre-wired Models (2 m) PVC (oil-resistant) --- --- E2E-X10T1 2M

Note: Not compliant with CE.

3-Wire Models

Shielded DC 3-Wire Models

E2E Lineup 25

Ap-
pear-
ance
Sensing
distance
Con-
nection
method
Cable
specifi-
cations
Opera-
tion
mode
Pin
arrange-
ment
Appli-
cable
con-
nector
code *2
Model
NPN output PNP output
M8 1.5 mm Pre-wired
Models
(2 m)
PVC (oil-
resistant)
NO --- --- E2E-X1R5E1 2M E2E-X1R5F1 2M
PVC (oil-
resistant)
NC E2E-X1R5E2 2M E2E-X1R5F2 2M
M12
Connector
Models
--- NO 1: +V, 3: 0 V,
4: Control
output
B E2E-X1R5E1-M1 E2E-X1R5F1-M1
NC 1: +V, 3: 0 V,
2: Control
output
D E2E-X1R5E2-M1 E2E-X1R5F2-M1
M8
Connector
Models
--- NO 1: +V, 3: 0 V,
4: Control
output
I E2E-X1R5E1-M3 E2E-X1R5F1-M3
NC 1: +V, 3: 0 V,
2: Control
output
E2E-X1R5E2-M3 E2E-X1R5F2-M3
M12 2 mm Pre-wired
Models
(2 m)
PVC (oil-
resistant)
NO --- --- E2E-X2E1 2M *1 E2E-X2F1 2M *1
NC E2E-X2E2 2M E2E-X2F2 2M
M12
Connector
Models
--- NO 1: +V, 3: 0 V,
4: Control
output
B E2E-X2E1-M1 E2E-X2F1-M1
NC 1: +V, 3: 0 V,
2: Control
output
D E2E-X2E2-M1 E2E-X2F2-M1
M18 5 mm Pre-wired
Models
(2 m)
PVC (oil-
resistant)
NO --- --- E2E-X5E1 2M *1 E2E-X5F1 2M *1
NC E2E-X5E2 2M E2E-X5F2 2M
M12
Connector
Models
--- NO 1: +V, 3: 0 V,
4: Control
output
B E2E-X5E1-M1 E2E-X5F1-M1
NC 1: +V, 3: 0 V,
2: Control
output
D E2E-X5E2-M1 E2E-X5F2-M1
M30 10 mm Pre-wired
Models
(2 m)
PVC (oil-
resistant)
NO --- --- E2E-X10E1 2M *1 E2E-X10F1 2M
NC E2E-X10E2 2M E2E-X10F2 2M
M12
Connector
Models
--- NO 1: +V, 3: 0 V,
4: Control
output
B E2E-X10E1-M1 E2E-X10F1-M1
NC 1: +V, 3: 0 V,
2: Control
output
D E2E-X10E2-M1 E2E-X10F2-M1

*1. Models with different frequencies are also available. The model number is E2E-X[][][]5 (example: E2E-X5E15 2M).
*2. Refer to Data Sheet for details.

Unshielded DC 3-Wire Models

E2E Lineup 27

Ap-
pear-
ance
Sensing
distance
Con-
nection
method
Cable
specifi-
cations
Opera-
tion
mode
Pin
arrange-
ment
Appli-
cable
con-
nector
code *2
Model
NPN output PNP output
M8 2 mm Pre-wired
Models
(2 m)
PVC (oil-
resistant)
NO --- --- E2E-X2ME1 2M E2E-X2MF1 2M
NC E2E-X2ME2 2M E2E-X2MF2 2M
M12
Connector
Models
--- NO 1: +V, 3: 0 V,
4: Control
output
B E2E-X2ME1-M1 E2E-X2MF1-M1
NC 1: +V, 3: 0 V,
2: Control
output
D E2E-X2ME2-M1 E2E-X2MF2-M1
M8
Connector
Models
--- NO 1: +V, 3: 0 V,
4: Control
output
I E2E-X2ME1-M3 E2E-X2MF1-M3
NC 1: +V, 3: 0 V,
2: Control
output
E2E-X2ME2-M3 E2E-X2MF2-M3
M12 5 mm Pre-wired
Models
(2 m)
PVC (oil-
resistant)
NO --- --- E2E-X5ME1 2M *1 E2E-X5MF1 2M
NC E2E-X5ME2 2M E2E-X5MF2 2M
M12
Connector
Models
--- NO 1: +V, 3: 0 V,
4: Control
output
B E2E-X5ME1-M1 E2E-X5MF1-M1
NC 1: +V, 3: 0 V,
2: Control
output
D E2E-X5ME2-M1 E2E-X5MF2-M1
M18 10 mm Pre-wired
Models
(2 m)
PVC (oil-
resistant)
NO --- --- E2E-X10ME1 2M *1 E2E-X10MF1 2M
NC E2E-X10ME2 2M E2E-X10MF2 2M
M12
Connector
Models
--- NO 1: +V, 3: 0 V,
4: Control
output
B E2E-X10ME1-M1 E2E-X10MF1-M1
NC 1: +V, 3: 0 V,
2: Control
output
D E2E-X10ME2-M1 E2E-X10MF2-M1
M30 18 mm Pre-wired
Models
(2 m)
PVC (oil-
resistant)
NO --- --- E2E-X18ME1 2M *1 E2E-X18MF1 2M
NC E2E-X18ME2 2M E2E-X18MF2 2M
M12
Connector
Models
--- NO 1: +V, 3: 0 V,
4: Control
output
B E2E-X18ME1-M1 E2E-X18MF1-M1
NC 1: +V, 3: 0 V,
2: Control
output
D E2E-X18ME2-M1 E2E-X18MF2-M1

*1. Models with different frequencies are also available. The model number is E2E-X[]M[][]5 (example: E2E-X5ME15 2M).
*2. Refer to Data Sheet for details.

Sensor I/O Connectors (Sockets on One Cable End)

Model for Connectors and Pre-wired Connectors: A Connector is not provided with the Sensor. Be sure to order a Connector separately.

Connector Applicable Proximity Sensor
model number
Screw Appearance
*1
Cable length 2m Cable length 5m
CablConnector
model number
CablConnector
model number
M12 Straight XS2F-D421-DA0-F XS2F-D421-GA0-F E2E-X[]D1-M1G(J)
L-shape XS2F-D422-DA0-F XS2F-D422-GA0-F
Straight XS2F-D421-DC0-F XS2F-D421-GC0-F E2E-X[]E1-M1
E2E-X[]F1-M1
L-shape XS2F-D422-DC0-F XS2F-D422-GC0-F
Straight XS2F-D421-DD0 XS2F-D421-GD0 E2E-X[]D1-M1J-T
E2E-X[]D1-M1
L-shape XS2F-D422-DD0 XS2F-D422-GD0 E2E-X[]D1-M1J-T
E2E-X[]D1-M1
Straight XS2F-D421-D80-F XS2F-D421-G80-F E2E-X[]D2-M1G(J)
E2E-X[]D2-M1J-T
E2E-X[]D2-M1
E2E-X[]D1S-M1
E2E-X[]E2-M1
E2E-X[]F2-M1
L-shape XS2F-D422-D80-F XS2F-D422-G80-F E2E-X[]D2-M1G(J)
E2E-X[]D2-M1J-T
E2E-X[]D2-M1
E2E-X[]D1S-M1
E2E-X[]E2-M1
E2E-X[]F2-M1
Straight XS2F-A421-DB0-F XS2F-A421-GB0-F E2E-X[]Y1-M1
L-shape XS2F-A422-DB0-F XS2F-A422-GB0-F
Straight XS2F-A421-D90-F XS2F-A421-G90-F E2E-X[]Y2-M1
Smartclick Connector,
Straight
XS5F-D421-D80-F XS5F-D421-G80-F E2E-X[]D1-M1TGJ(-US)
E2E-X[]D2-M1TGJ-US
Smartclick Connector,
Straight Oil-resistant
Reinforced Cables
XS5F-D421-D80-P XS5F-D421-G80-P E2E-X[]D1-M1TGJ-U
E2E-X[]D2-M1TGJ-U
M8 Straight XS3F-M421-402-A XS3F-M421-405-A E2E-X[]D1-M3G
E2E-X[]D2-M3G
E2E-X[]E1-M3
E2E-X[]F1-M3
E2E-X[]E2-M3
E2E-X[]F2-M3
L-shape XS3F-M422-402-A XS3F-M422-405-A E2E-X[]D1-M3G
E2E-X[]D2-M3G
E2E-X[]E1-M3
E2E-X[]F1-M3
E2E-X[]E2-M3
E2E-X[]F2-M3

Note: Refer to Introduction to Sensor I/O Connectors/Sensor Controllers for details and for information on Cable length
          and Robotics Cables.
*1. Images of straight and L-shaped connectors.

E2E Lineup 31

*2. Refer to Connection Diagrams on Data Sheet for information on Proximity Sensor and I/O Connector connections.
