EE-SPX840

Slot-type Photomicrosensor with Connector (Modulated)


Photomicrosensor, Slot type, Through-beam, Sensing distance: 3.6 mm (slot width), Light-ON, NPN output, Connector model

As of July 25, 2024


Type		Grooved Type
Luminous method		Modulated
Sensing method		Through-beam type
Sensing distance		Slot width: 3.6 mm
Operation mode		Light-ON
Standard sensing object		Opaque, 1 x 0.5 mm min.
Differential distance elements		0.05 mm max.
Light source （Peak wavelength）		GaAs infrared LED (pulse lighting) (940 nm)
Indicator		Light indicator (red)
Power supply voltage		5 to 24 VDC ±10% ripple (p-p) 5 % max.
Current consumption		Average value: 15 mA max. Peak: 50 mA max.
Control output	Output type	NPN voltage output
	Load power supply voltage	5 to 24 VDC
	Load curren	50 mA max.
	Residual voltage	at 50 mA load current: 1.0 V max. at 10 mA load current: 0.4 V max.
Response frequency elements		500 Hz min.
Illumination on the surface receiver		Incandescent light, sunlight: 3000 lx max.
Ambient temperature		Operating: -10 to 55 ℃ Storage: -25 to 65 ℃
Ambient humidity		Operating: 5 to 85 % Storage: 5 to 95 %
Vibration resistance		Destruction: 10 to 55 Hz, 1.5 mm double amplitude each in X, Y, and Z directions for 2 h
Shock resistance		Destruction: 500 m/s² for 3 times each in X, Y, and Z directions
Degree of protection		IP50
Connection method		Connector type
Weight		Approx. 2.4 g
Material		Case: Polycarbonate (PC) Holder: Polycarbonate (PC)
